Geometry

  XS S M ML L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 306 349 364 316 334 490
Stack 444 598 559 573 555 638
Top Tube (effective) 418 595 495 653 479 617
Seat Tube C-T 351 444 434 445 612 572
Head Angle 82 70 76 64 79 82
Seat Angle 66 83 69 65 86 65
Head Tube 114 121 135 129 164 225
Chainstay 447 418 423 329 340 355
Wheelbase 1065 805 805 1040 866 909
Front Centre 634 606 535 585 565 536
BB Drop 71 78 54 71 62 61
Fork Rake / Offset 47 39 48 49 45 43
Fork Length (A2C) 365 340 430 401 303 368
Data Source Gusto Gusto Gusto Gusto Gusto Gusto

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
