Geometry
| M | L | |
|---|---|---|
| Add to Compare | ||
| Reach | 444/440/435 | 472/468/463 |
| Stack | 559/602/605 | 612/616/619 |
| Top Tube (effective) | 596/598/599 | 630/630/632 |
| Seat Tube C-T | 373 | 361 |
| Head Angle | 65.5/65/64.5 | 65.5/65/64.5 |
| Seat Angle | 76/75.5/75 | 76/75.5/75 |
| Head Tube | 97 | 117 |
| Chainstay | 362 | 511 |
| Wheelbase | 1191/1195/1199 | 1225/1229/1233 |
| Standover | 743/746/748 | 757/760/762 |
| BB Drop | 13/10/7 | 13/10/7 |
| BB Height | 341/344/347 | 341/344/347 |
| BB Type | BSA 73mm | BSA 73mm |
| Seatpost Diameter | 35 | 32 |
| Axle Spacing | 12x148 boost | 12x148 boost |
| Wheel Size | 23 | 25 |
| Tyre Max Width | 2 | 2 |
| Front Travel | 170 | 139 |
| Rear Travel | 143 | 201 |
| Shock Size | 230x62.5 | 230x62.5 |
| Headset | IS42/52 | IS42/52 |
| Seat Clamp | Integrated | Integrated |
| Frame Weight | 3.5kg | 3.5kg |
| Data Source | Manufacturer | Manufacturer |
Note: Weight without shock.
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
