my custom build my custom build 2016


c

Geometry

  XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 433
Stack 739
Top Tube (effective) 630
Top Tube (actual) 510
Seat Tube C-T 711
Seat Tube C-C 492
Seat Tube (effective) 776
Head Tube 197
Chainstay 450
Wheelbase 1208
Front Centre 556
BB Drop 67
Fork Rake / Offset 49
Fork Length (A2C) 325
Data Source Me, my own custom made frame, John Bikes

Note: Custom made to fit me, John

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
