Geometry

  50 cm 53 cm 56 cm 58 cm 61 cm
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 371 373 358 329 335
Stack 425 628 512 627 705
Top Tube (effective) 467 569 454 640 563
Seat Tube C-T 408 489 580 570 675
Head Angle 71 72 70 58 83
Seat Angle 68 70 63 65 79
Head Tube 93 107 160 147 166
Chainstay 380 458 474 469 406
Wheelbase 1008 1062 1199 1143 1078
Standover 895 834 832 921 804
BB Drop 59 63 57 57 69
Seatpost Diameter 25 25 21 30 26
Wheel Size 817 696 685 675 817
Tyre Max Width 33 35 40 39 32
Seatpost Length 315 360 317 321 473
Handlebar Width 378 338 381 397 459
Stem Length 79 75 95 106 117
Stem Angle -5 -5 -5 -5 -6
Crank Length 148 192 205 199 163
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
