| P1 | P2 | P3 | P4 | |
|---|---|---|---|---|
| Add to Compare | ||||
| Reach | 504 | 377 | 477 | 553 |
| Stack | 625 | 690 | 602 | 568 |
| Top Tube (effective) | 529 | 691 | 502 | 566 |
| Seat Tube C-T | 407 | 390 | 419 | 456 |
| Head Angle | 69 | 52 | 63 | 67 |
| Seat Angle | 77 | 77 | 79 | 87 |
| Head Tube | 127 | 99 | 112 | 158 |
| Chainstay | 440 - 450 | 440 - 450 | 445 - 455 | 450 - 460 |
| Wheelbase | 1212 - 1222 | 1237 - 1247 | 1268 - 1278 | 1307 - 1317 |
| Front Centre | 749 | 744 | 917 | 713 |
| BB Drop | 34 | 26 | 27 | 25 |
| Fork Rake / Offset | 40 | 46 | 41 | 44 |
| Axle to Crown | 601 | 603 | 644 | 660 |
| Fork Length (A2C) | 540 | 486 | 473 | 537 |
| Seatpost Diameter | 32 | 34 | 30 | 29 |
| Axle Spacing | Boost 148mm | Boost 148mm | Boost 148mm | Boost 148mm |
| Max Post Insertion | 218 | 308 | 347 | 382 |
| Shock Size | 220 | 210 | 169 | 178 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
