| S1 | S2 | S3 | S4 | S5 | |
|---|---|---|---|---|---|
| Add to Compare | |||||
| Reach | 366 | 456 | 502 | 519 | 567 |
| Stack | 482 | 571 | 577 | 651 | 550 |
| Top Tube (effective) | 457 | 676 | 683 | 564 | 648 |
| Seat Tube C-T | 408 | 410 | 359 | 515 | 399 |
| Head Angle | 65 | 68 | 64 | 70 | 75 |
| Seat Angle | 90 | 64 | 77 | 69 | 78 |
| Head Tube | 95 | 104 | 135 | 124 | 122 |
| Chainstay | 507 | 355 | 425 | 408 | 457 |
| Wheelbase | 1338 | 1077 | 1116 | 1153 | 1526 |
| Front Centre | 852 | 647 | 762 | 985 | 710 |
| Standover | 687 | 833 | 832 | 841 | 638 |
| BB Drop | 33 | 26 | 30 | 32 | 35 |
| BB Height | 399 | 302 | 396 | 284 | 345 |
| BB Type | threaded BB | threaded BB | threaded BB | threaded BB | threaded BB |
| Fork Rake / Offset | 44 | 51 | 43 | 50 | 37 |
| Trail | 136 | 105 | 122 | 144 | 137 |
| Fork Length (A2C) | 608 | 551 | 565 | 584 | 474 |
| Seatpost Diameter | 31 | 28 | 37 | 34 | 33 |
| Seatpost Length | 121 | 175 | 142 | 202 | 214 |
| Dopper Post Travel | 125mm | 150mm | 170mm | 170mm | 190mm |
| Handlebar Width | 759 | 873 | 734 | 814 | 751 |
| Stem Length | 42 | 45 | 33 | 34 | 42 |
| Crank Length | 168 | 199 | 192 | 151 | 138 |
| Front Travel | 140mm | 140mm | 140mm | 140mm | 140mm |
| Rear Travel | 140mm | 140mm | 140mm | 140mm | 140mm |
| Shock Size | 210x50mm | 210x52.5mm | 210x52.5mm | 210x52.5mm | 210x52.5mm |
| Rider Height | 150-160cm | 157-173cm | 165-180cm | 173-188cm | 178cm+ |
| Bike Weight | 15.29 kg | ||||
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
