TREK Allant 7.4 2016


c

Geometry

  15 in 17.5 in 20 in 22.5 in 25 in
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 466 549 632 590 645
Seat Tube C-T 346 433 548 495 510
Head Angle 83 76 82 80 69
Seat Angle 83 88 73 63 61
Head Tube 133 124 177 178 214
Chainstay 444 478 406 394 518
Wheelbase 871 914 1168 1103 1026
Standover 584 621 750 836 1007
BB Drop 57 56 42 46 45
BB Height 338 331 257 330 237
Trail 68 63 82 67 63
Seatpost Diameter 27,2
Wheel Size 675
Stem Length 90
Stem Angle 6
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
