Geometry
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Add to Compare | |||||
| Reach | 431 | 410 | 350 | 311 | 330 |
| Stack | 438 | 564 | 571 | 500 | 523 |
| Top Tube (effective) | 513 | 587 | 485 | 484 | 608 |
| Seat Tube C-C | 366 | 491 | 483 | 571 | 446 |
| Head Angle | 73 | 83 | 64 | 61 | 59 |
| Seat Angle | 66 | 71 | 76 | 71 | 84 |
| Head Tube | 105 | 107 | 146 | 155 | 148 |
| Chainstay | 375 | 419 | 456 | 361 | 386 |
| Wheelbase | 975 | 1024 | 862 | 1006 | 1000 |
| Standover | 777 | 831 | 888 | 774 | 836 |
| BB Drop | 67 | 80 | 63 | 71 | 77 |
| BB Height | 293 | 313 | 318 | 222 | 306 |
| BB Type | BSA | BSA | BSA | BSA | BSA |
| Fork Rake / Offset | 53 | 49 | 45 | 41 | 36 |
| Trail | 56 | 57 | 73 | 68 | 51 |
| Fork Length (A2C) | 433 | 403 | 352 | 360 | 423 |
| Tyre Max Width | 700x34 | 700x34 | 700x34 | 700x34 | 700x34 |
| Seatpost Length | 309 | 379 | 300 | 362 | 344 |
| Seatpost Offset | 0 | 0 | 16 | 15 | 17 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
