Geometry

  XS SM MD L G XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 321 413 486 433 551
Stack 514 643 674 663 555
Top Tube (effective) 481 503 693 493 592
Top Tube (actual) 540 523 530 472 736
Seat Tube C-T 322 347 384 382 459
Head Angle 56 60 74 61 76
Seat Angle 62 84 75 67 71
Head Tube 95 104 114 139 127
Chainstay 356 373 375 430 406
Wheelbase 1066 954 1221 1314 1472
Front Centre 646 867 683 651 853
Standover 728 707 760 632 908
BB Drop 14 40 27 37 29
BB Height 332 360 289 319 348
Fork Rake / Offset 33 47 42 35 42
Trail 137 154 112 155 126
Wheel Size 27.5" 29" 29" 29" 29"
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
