Geometry

  XS SM MD L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 423 415 428 370 418
Stack 400 439 567 634 502
Head Angle 62 65 86 77 65
Seat Angle 77 83 72 78 76
Head Tube 96 93 117 172 195
Chainstay 345 421 366 452 440
Front Centre 535 689 567 561 689
BB Drop 78 64 80 69 65
BB Type BSA BSA BSA BSA BSA
Fork Rake / Offset 47 51 45 46 43
Trail 52 51 58 49 62
Fork Length (A2C) 355 366 323 433 350
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
