Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 404 399 447 327 461
Stack 468 550 541 620 524
Top Tube (effective) 592 495 516 665 596
Seat Tube C-T 419 526 519 469 565
Head Angle 67 79 68 60 73
Seat Angle 66 59 61 76 79
Head Tube 95 134 166 176 234
Chainstay 426 359 379 344 445
Wheelbase 963 1038 992 1029 897
Front Centre 538 602 469 596 740
Standover 627 621 795 875 873
BB Drop 57 59 67 53 76
BB Height 295 249 217 271 299
BB Type PF BB86/BB92 (86.5mm) PF BB86/BB92 (86.5mm) PF BB86/BB92 (86.5mm) PF BB86/BB92 (86.5mm) PF BB86/BB92 (86.5mm)
Fork Rake / Offset 52 40 34 44 36
Trail 51 67 47 46 69
Fork Length (A2C) 352 333 323 390 409
Seatpost Diameter 30 25 31 22 27
Stem Length 101 110 115 108 98
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
