Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Add to Compare | ||||||
| Reach | 419 | 429 | 454 | 426 | 332 | 407 |
| Stack | 538 | 609 | 493 | 588 | 689 | 518 |
| Top Tube (effective) | 533 | 604 | 514 | 545 | 524 | 541 |
| Seat Tube C-C | 424 | 392 | 539 | 402 | 439 | 609 |
| Head Angle | 58 | 59 | 83 | 66 | 64 | 88 |
| Seat Angle | 71 | 82 | 73 | 81 | 72 | 59 |
| Head Tube | 130 | 125 | 124 | 163 | 155 | 189 |
| Chainstay | 404 | 449 | 329 | 469 | 481 | 481 |
| Wheelbase | 1161 | 1150 | 904 | 1011 | 1186 | 1099 |
| Front Centre | 546 | 605 | 536 | 520 | 654 | 713 |
| BB Drop | 79 | 62 | 86 | 71 | 73 | 72 |
| BB Type | T47 | T47 | T47 | T47 | T47 | T47 |
| Fork Rake / Offset | 44 | 48 | 55 | 48 | 41 | 40 |
| Fork Length (A2C) | 410 | 409 | 390 | 314 | 415 | 364 |
| Axle Spacing | 12*142mm | 12*142mm | 12*142mm | 12*142mm | 12*142mm | 12*142mm |
| Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Tyre Max Width | 32C / 40mm? | 32C / 40mm? | 32C / 40mm? | 32C / 40mm? | 32C / 40mm? | 32C / 40mm? |
| Seatpost Length | 350/400mm | 350/400mm | 350/400mm | 350/400mm | 350/400mm | 350/400mm |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
