Geometry

  M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 412 565 497
Stack 718 619 710
Top Tube (effective) 600 572 569
Top Tube (actual) 559 739 674
Head Angle 60 73 65
Seat Angle 69 74 62
Head Tube 109 131 111
Chainstay 477 534 364
Wheelbase 1180 1093 1104
Standover 696 864 884
BB Height 366 343 349
Fork Rake / Offset 47 39 48
Rear Travel 160 150 117
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
