| S | M | L | XL | |
|---|---|---|---|---|
| Add to Compare | ||||
| Reach | 443 | 419 | 515 | 582 |
| Stack | 669 | 556 | 540 | 530 |
| Top Tube (effective) | 599 | 503 | 523 | 558 |
| Seat Tube C-T | 347 | 399 | 400 | 582 |
| Head Angle | 62 | 69 | 72 | 75 |
| Seat Angle | 67 | 83 | 80 | 68 |
| Head Tube | 84 | 91 | 86 | 108 |
| Chainstay | 356 | 351 | 374 | 386 |
| Wheelbase | 1173 | 1269 | 1167 | 1166 |
| Standover | 798 | 780 | 905 | 639 |
| BB Drop | 44 | 40 | 38 | 48 |
| BB Height | 281 | 286 | 288 | 385 |
| BB Type | PRESS FIT | PRESS FIT | PRESS FIT | PRESS FIT |
| Fork Rake / Offset | 41 | 46 | 36 | 43 |
| Trail | 1100 | 1114 | 1320 | 1379 |
| Fork Length (A2C) | 624 | 597 | 492 | 553 |
| Seatpost Diameter | 29 | 28 | 31 | 28 |
| Max Post Insertion | 138 | 203 | 252 | 319 |
| Stem Length | 43 | 63 | 67 | 87 |
| Front Travel | 118 | 136 | 98 | 96 |
| Rear Travel | 129 | 100 | 98 | 100 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
