Geometry

  49 52 54 56 58 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 349 335 364 442 465 330
Stack 510 575 486 474 615 622
Top Tube (effective) 501 463 549 530 498 703
Seat Tube C-T 415 412 547 523 492 620
Head Angle 71.75° 72.5° 73° 73.5° 73.5° 74°
Seat Angle 75.5° 74° 74° 73.5° 73.5° 73°
Head Tube 101 115 133 169 165 201
Chainstay 410 405 448 366 419 425
Wheelbase 1132 1075 978 1036 1187 833
Front Centre 517 600 555 695 581 667
Standover 875 804 911 837 826 792
BB Drop 84 77 73 59 72 81
BB Height 299 216 242 243 220 220
Fork Rake / Offset 42 41 48 43 35 45
Trail 74 49 62 55 50 54
Fork Length (A2C) 375 400 295 298 357 410
Stem Length 72 80 75 91 102 93
Rider Height 152 - 163 163 - 170 168 - 175 175 - 183 180 - 188 188 - 196
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
