Trek Supercaliber 9.6 2022


c

Geometry

  15.5 17.5 18.5 19.5 21.5
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 461 399 456 433 509
Stack 585 612 580 486 716
Top Tube (effective) 565 548 531 723 703
Seat Tube C-T 422 364 373 551 594
Head Angle 75 71 70 67 79
Seat Angle 75 64 87 64 60
Head Tube 75 87 79 100 84
Chainstay 387 405 502 454 505
Wheelbase 1292 1127 1324 1063 1336
Standover 783 633 912 866 866
BB Drop 51 62 62 58 66
BB Height 273 262 332 353 329
Fork Rake / Offset 40 48 45 44 40
Trail 115 99 108 117 97
Wheel Size 29" 29" 29" 29" 29"
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
